Medium-Alumina Aluminosilicate Glass for LiDAR and Depth Sensor Windows

Name: Medium-Alumina Aluminosilicate Glass for LiDAR and Depth Sensor Windows
Brand: Hunan Xinghuai New Material Co., Ltd
SKU: CHIYAN-M2
Price: negotiable USD
Availability: InStock

Brand Name:	CHIYAN
Model Number:	CHIYAN-M2
MOQ:	1000square meters
Price:	Negotiable
Payment Terms:	T/T in advanced
Supply Ability:	1000000000square meters

Detail Information

Product Description

Detail Information

Place of Origin:

MADE IN CHINA

Certification:

CE ROHS etc.

Standard Thickness:

0.5-10.0mm

Touchsensitivity:

High

Impact Resistance:

High

Optional Thickness:

0.25mm~2mm

Transparency:

≥90%

Scratch Resistance:

High

Thickness Available:

0.25mm~2.5mm

Printinng:

Silk-screen Printing

Packaging Details:

wooden box

Supply Ability:

1000000000square meters

Product Description

1. Product Title

Medium-Alumina Aluminosilicate Glass for LiDAR and Depth Sensor Windows

2. Product Keywords

medium aluminosilicate glass, aluminosilicate float glass, ultra clear glass sheet, thin glass sheet, 0.5mm glass, 0.55mm glass, 0.7mm glass, 0.82mm glass, 0.95mm glass, 1mm glass, 1.1mm glass, 1.3mm glass, 1.5mm glass, 1.6mm glass, 1.8mm glass, 2mm glass, 2.5mm glass, display glass, display cover glass, display substrate glass, electronic glass, chemically strengthenable glass, thin float glass, clear float glass

3. Short Description

CHIYAN-M2 is an ultra clear medium aluminosilicate float glass sheet available from 0.5mm to 2.5mm, featuring high optical transmittance, controlled flatness and chemical strengthening capability for display, electronic and optoelectronic applications.

4. Product Overview

CHIYAN-M2 is an ultra clear medium aluminosilicate float glass developed by Hunan Xinghuai New Material Technology Co., Ltd. for applications requiring thin glass, high optical transmittance and good flatness.
The product is manufactured using the float glass process and is available in thicknesses from 0.50mm to 2.50mm.
CHIYAN-M2 is designed for applications including display cover glass, display substrates, electronic, microelectronic and optoelectronic applications.
The standard supply size is 1300 × 1100mm, and other dimensions can be discussed according to customer requirements.
The product specification defines different thickness tolerances and flatness requirements according to the thickness range, allowing customers to select a suitable specification for their application.

5. Key Features

Ultra Clear Optical Performance

Optical transmittance is specified at ≥91.5% according to GB/T 2680-2021.

Medium Aluminosilicate Glass

CHIYAN-M2 is a medium aluminosilicate glass developed for applications requiring specialized glass properties in electronic, display and optoelectronic fields.

Controlled Flatness

The specified pre-strengthening flatness is:

0.50-0.55mm: ≤0.15% (h/L)
0.70-2.50mm: ≤0.10% (h/L)

Chemical Strengthening Capability

CHIYAN-M2 provides reference chemical strengthening process parameters for different ion-exchange temperatures and strengthening levels.
Reference strengthening grades include 1.5H, 2H, 3H, 4H and 5H.
Actual strengthening results may vary depending on processing conditions.

Wide Thickness Selection

Available thicknesses include:
0.50mm, 0.55mm, 0.70mm, 0.82mm, 0.95mm, 1.00mm, 1.10mm, 1.30mm, 1.50mm, 1.60mm, 1.80mm, 2.00mm and 2.50mm.

Float Glass Process

Manufactured using the float glass process, providing a flat and smooth glass surface suitable for subsequent processing.

6. Available Thicknesses

Thickness	Availability
0.50mm	Available
0.55mm	Available
0.70mm	Available
0.82mm	Available
0.95mm	Available
1.00mm	Available
1.10mm	Available
1.30mm	Available
1.50mm	Available
1.60mm	Available
1.80mm	Available
2.00mm	Available
2.50mm	Available

The above thicknesses are listed in the current product specification. Packaging quantity may vary according to the actual packing condition.

7. Technical Specifications

Item	Specification
Product Name	CHIYAN-M2
Glass Type	Ultra Clear Medium Aluminosilicate Float Glass
Manufacturing Process	Float Glass
Thickness Range	0.50-2.50mm
Standard Size	1300 × 1100mm
Size Tolerance	±2mm
Thickness Tolerance	0.50-1.10mm: ±0.05mm
	1.30-2.50mm: ±0.10mm
Thickness Difference	≤0.04mm
Diagonal Difference / Squareness	≤0.3%
Pre-strengthening Flatness	0.50-0.55mm: ≤0.15% (h/L)
	0.70-2.50mm: ≤0.10% (h/L)
Optical Transmittance	≥91.5%

The standard sheet size is 1300 × 1100mm, with other dimensions available for discussion according to customer requirements.
The dimensional and flatness requirements above are based on the product quality specification.

8. Physical Properties

Property	Unit	Reference Value
Density	g/cm³	2.48 ± 0.01
Refractive Index	-	1.51 ± 0.01
Young's Modulus	GPa	73.0 ± 0.5
Optical Transmittance	%	≥91.5
Volume Resistivity	lg(Ω·cm)	≥10.0
Dielectric Constant	-	≥7.0
Softening Point	ºC	750 ± 10
Strain Point	ºC	516 ± 5
Annealing Point	ºC	562 ± 5
Thermal Conductivity	W/(m·K)	0.682 ± 0.10
Thermal Expansion Coefficient	×10/ºC	85 ± 5
Photoelastic Constant	nm/cm/MPa	27.0 ± 0.2
Poisson's Ratio	-	0.23 ± 0.02
Vickers Hardness	HV	610 ± 10

9. Chmical Strengthening Capability

CHIYAN-M2 can be chemically strengthened through ion-exchange processing.
The product specification provides reference process parameters for different strengthening temperatures and grades.
Reference strengthening grades include:

Time	400°C		410°C		420°C		430°C
Time	CS (MPa)	DOL (um)	CS (MPa)	DOL (um)	CS (MPa)	DOL (um)	CS (MPa)	DOL (um)
3H	≥650	≥7.0	≥650	≥8.0	≥650	≥9.0	≥650	≥10.5
4H	≥600	≥8.0	≥600	≥9.0	≥600	≥11.0	≥600	≥12.5
5H	≥600	≥9.0	≥600	≥10.0	≥600	≥11.5	≥600	≥13.0

For 3H, 4H and 5H strengthening conditions, reference surface compressive stress (CS) and depth of layer (DOL) values are provided for different process temperatures.
Note: The chemical strengthening data in the product specification are process reference values. Actual results may vary depending on the glass processing conditions and are not intended to serve as guaranteed production values.

10. Chemical Stability

Test	Test Condition	Reference Value
Acid Resistance - HCl	5% HCl, 95±0.5ºC, 24h	≤0.05mg/cm²
Acid Resistance - HF	10% HF, 20±0.5ºC, 20min	≤9.00mg/cm²
Alkali Resistance - NaOH	5% NaOH, 95±0.5ºC, 6h	≤0.35mg/cm²

The above chemical stability values are reference values specified in the product specification.

11. Applications

CHIYAN-M2 Medium Aluminosilicate Glass is suitable for a variety of applications requiring high optical clarity, thin thickness, good surface hardness, dimensional stability and chemical strengthening capability. Typical and potential applications include:

1. Display and Electronic Applications

Display Cover Glass
Display Substrate
Electronic Display Panels
Industrial Display Panels
Touch Panels
Touch Screen Applications

2. Automotive Applications

Automotive Display Glass
Automotive Electronics
Head-Up Display (HUD) Applications
In-Vehicle Display Systems
Automotive Control Panels

3. Photovoltaic Applications

Lightweight Photovoltaic Applications
Thin Solar Glass Applications
High Transmittance Solar Applications
Lightweight Solar Modules and Components

4. Industrial and Control Applications

Industrial Touch Panels
Industrial Control Panels
Industrial Instrument Panels
HMI (Human-Machine Interface) Panels
Equipment Display Panels
Machine Control Interfaces

5. Smart Home and Consumer Electronics

Smart Home Control Panels
Smart Switch Panels
Electronic Switch Panels
Home Automation Control Panels
Appliance Control Panels

6. Optical and Instrument Applications

Optical Instrument Components
Optical Windows
Sensor Windows
Protective Windows
Optical Equipment Components

7. Laboratory and Medical Applications

Microscope Slide Applications
Laboratory Glass Components
Medical Equipment Display Panels
Medical Instrument Components
Laboratory Equipment Components

8. Mirror and Decorative Applications

High Definition Mirror Applications
High Clarity Mirror Substrates
Thin Mirror Applications
Decorative Glass Applications

9. Other Industrial Applications

Precision Glass Components
Protective Glass Components
Glass Substrates
Custom Industrial Glass Applications
Other Applications Requiring Thin, Clear and Chemically Strengthenable Glass

12. Quality & Appearance

The effective quality area is defined as the area 10mm outside all edges.
The product quality specification covers requirements for:

Scratches
Bubbles
Stones and inclusions
Tin spots
Edge chips
Cracks
Surface contamination

Quality inspection is carried out according to the applicable product quality specifications and sampling requirements.

13. Processing

CHIYAN-M2 is supplied as float glass sheets / raw glass sheets for subsequent customer processing.
Depending on the customer's application and processing requirements, the glass may be used for processes such as:

Chemical strengthening
Cutting
CNC processing
Other downstream processing

CNC processing parameters are available as reference information upon request.

14. Packaging

Standard packaging includes:

Wooden frame / wooden crate packaging
Interleaving paper
Desiccant
Glass protection against breakage

Reference packaging quantities vary according to glass thickness.

Thickness	Reference Quantity
0.50mm	755 pcs/box
0.55mm	680 pcs/box
0.70mm	550 pcs/box
0.82mm	490 pcs/box
0.95mm	420 pcs/box
1.00mm	410 pcs/box
1.10mm	370 pcs/box
1.30mm	310 pcs/box
1.50mm	270 pcs/box
1.60mm	260 pcs/box
1.80mm	230 pcs/box
2.00mm	210 pcs/box
2.50mm	168 pcs/box

Note: Packaging quantities are for reference only and may vary according to actual packing conditions.

15. Storage

Recommended storage conditions:

Temperature: ≤30ºC
Humidity: ≤65%
Avoid condensation on the glass surface

The quality guarantee period is 6 months from the delivery date under the specified storage conditions.

16. Why Choose CHIYAN-M2?

Specialized Material

Medium aluminosilicate glass developed for electronic, display and optoelectronic applications.

High Optical Transmittance

Optical transmittance of ≥91.5%.

Controlled Flatness

Flatness of ≤0.10% (h/L) for 0.70-2.50mm thicknesses.

Chemical Strengthening Capability

Reference ion-exchange process parameters are available for different strengthening conditions.

Multiple Thickness Options

Multiple standard thicknesses from 0.50mm to 2.50mm are available.

Flexible Sheet Dimensions

Standard size is 1300 × 1100mm, with other dimensions available for discussion according to customer requirements.

17. FAQ

Q1: What thicknesses are available?

CHIYAN-M2 is available from 0.50mm to 2.50mm, including 0.50, 0.55, 0.70, 0.82, 0.95, 1.00, 1.10, 1.30, 1.50, 1.60, 1.80, 2.00 and 2.50mm.

Q2: What is the standard sheet size?

The standard supply size is 1300 × 1100mm. Other dimensions can be discussed according to customer requirements.

Q3: What is the optical transmittance?

The specified optical transmittance is ≥91.5%.

Q4: Can CHIYAN-M2 be chemically strengthened?

Yes. The product specification provides reference chemical strengthening process parameters for different strengthening conditions.

Q5: Is CHIYAN-M2 supplied as raw glass sheet?

Yes. CHIYAN-M2 is supplied as float glass sheets for subsequent customer processing and applications.

Q6: What is the thickness tolerance?

For 0.50-1.10mm, the thickness tolerance is ±0.05mm.
For 1.30-2.50mm, the thickness tolerance is ±0.10mm.

Q7: What is the flatness?

For 0.50-0.55mm, the specified pre-strengthening flatness is ≤0.15% (h/L).
For 0.70-2.50mm, the specified pre-strengthening flatness is ≤0.10% (h/L).

Q8: Can you provide customized sizes?

Yes. The standard size is 1300 × 1100mm, and other dimensions can be discussed according to customer requirements.

Q9: What is the minimum order quantity?

MOQ: To be discussed according to thickness, size and order requirements.

18. B2B Inquiry Call-to-Action

Looking for medium aluminosilicate glass for your display or electronic application?
Please send us your requirements:
Thickness + Size + Quantity + Application
Our team can evaluate the suitable CHIYAN-M2 specification and provide a quotation accordingly.
Hunan Xinghuai New Material Technology Co., Ltd.
Sophia

CHIYAN-M2 | Ultra Clear Medium Aluminosilicate Float Glass

Tags:

Display Cover Glass

Soda Lime Glass/ Medium Aluminosilicate Glass

Aluminosilicate Glass

Screen Protector Glass

Touch Panel Cover Glass

Automotive Laminated Glass

Ultra Thin Glass

Foldable Display Screen

Smart Home Display Screen

ITO Conductive Glass

Solar Photovoltaic Glass

Insulating Glass Units

High Definition Mirror

Lithium Aluminosilicate Glass

Ceramic Phone Screen

Display Cover Glass

Soda Lime Glass/ Medium Aluminosilicate Glass

Aluminosilicate Glass

Screen Protector Glass

Touch Panel Cover Glass

Automotive Laminated Glass

Ultra Thin Glass

Foldable Display Screen

Smart Home Display Screen

ITO Conductive Glass

Solar Photovoltaic Glass

Insulating Glass Units

High Definition Mirror

Lithium Aluminosilicate Glass

Ceramic Phone Screen

products details

Medium-Alumina Aluminosilicate Glass for LiDAR and Depth Sensor Windows

Medium-Alumina Aluminosilicate Glass for LiDAR and Depth Sensor Windows

Product Description

1. Product Title

2. Product Keywords

3. Short Description

4. Product Overview

5. Key Features

Ultra Clear Optical Performance

Medium Aluminosilicate Glass

Controlled Flatness

Chemical Strengthening Capability

Wide Thickness Selection

Float Glass Process

6. Available Thicknesses

7. Technical Specifications

8. Physical Properties

9. Chmical Strengthening Capability

10. Chemical Stability

11. Applications

1. Display and Electronic Applications

2. Automotive Applications

3. Photovoltaic Applications

4. Industrial and Control Applications

5. Smart Home and Consumer Electronics

6. Optical and Instrument Applications

7. Laboratory and Medical Applications

8. Mirror and Decorative Applications

9. Other Industrial Applications

12. Quality & Appearance

13. Processing

14. Packaging

15. Storage

16. Why Choose CHIYAN-M2?

Specialized Material

High Optical Transmittance

Controlled Flatness

Chemical Strengthening Capability

Multiple Thickness Options

Flexible Sheet Dimensions

17. FAQ

Q1: What thicknesses are available?

Q2: What is the standard sheet size?

Q3: What is the optical transmittance?

Q4: Can CHIYAN-M2 be chemically strengthened?

Q5: Is CHIYAN-M2 supplied as raw glass sheet?

Q6: What is the thickness tolerance?

Q7: What is the flatness?

Q8: Can you provide customized sizes?
