Original Aluminosilicate ITO Conductive Glass Impact Resistant 1.50mm

Name: Original Aluminosilicate ITO Conductive Glass Impact Resistant 1.50mm
Brand: Hunan Xinghuai New Materials Technology Co., Ltd.
SKU: CHIYAN-M1
Availability: InStock

Brand Name:	CHIYAN
Model Number:	CHIYAN-M1
MOQ:	10000 square meters
Price:	Negotiable
Payment Terms:	,T/T,Western Union
Supply Ability:	Annual output 20 million square meters

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO14001/ISO9001/ RHOS/ REACH/ CP65/ Holagon Free

Name:

Original Aluminosilicate ITO Conductive Glass Impact Resistant 1.50mm

Regular Thickness:

0.25~2.0mm

Packaging Details:

Wooden Box/ Pallet

Supply Ability:

Annual output 20 million square meters

Highlight:

Aluminosilicate ITO Conductive Glass

Impact Resistant ITO Conductive Glass

ITO Conductive Glass 1.50mm

Product Description

CHIYAN Aluminosilicate glass original Sheet processed for ITO Conductive Glass

Green Medium Aluminosilicate Glass(CHIYAN-M1) is an environmental-friendly ultra-thin aluminosilicate glass with certain strength.

Features:

High Impact Resistance

High Scratch Resistance

High Transmittance

High chemical resistance

Application: Widely used in consumer electronics cover, vehicle display, industrial touch panels, smart home screen display, ITO conductive fields;

Regular Thickness:

2.0mm 1.80mm 1.50mm 1.30mm

1.10mm 0.70mm 0.55mm

0.40mm 0.33mm 0.25mm

CHIYAN-M1’s 0.25~2.0mm thickness medium alumino-silicate glass has already been used in the market to meet a wide range of customers needs.

Standard Size:1300*1100mm (5th Generation)

1092.2*1244.6mm

Note: The size can be customized according to customer's needs.

Product Composition

Medium Alumino-Silicate Glass achieves better stress and strain depth than ordinary soda-lime glass by increasing the Al₂O₃ content in the glass and increasing the ion exchange capacity.

Physical Property Parameter

S/N	Items	Unit	Test Standard	CY-M2
1	Density	g/cm3	GB/T5432-2008	2.48±0.01
2	Refractive Index	/	GB/T 2680-2021	1.51±0.01
3	Young's Modulus	Gpa	GB/T 37780-2019	73.0±0.5
4	Transmittance	%	GB/T 2680-2021	≥91
5	Volume Resistivity	lg(Ω .cm)	GB/T 31838.2-2019	6.8
6	Dielectric Constant	F/m	SJ/T 11043-1996	7.6
7	Softening Point	℃	GB/T 28195-2011	739±10
8	Strain Point	℃	GB/T 28196-2011	514±5
9	Annealing Point	℃	GB/T 28196-2011	555±5
10	Thermal Expansivity	* 10-7/℃	SJ/T 11036-1996	85±5
11	Photoelastic Coefficient	nm/cm/MPa	BS 7604-1-1992	27.0±0.2
12	Poisson's Coefficient	/	GB/T 28195-2011	0.23±0.02
13	Vickers-hardness	HV	GB/T 16534-2009	580±10

Chemical Tempering Process Parameter Setting Reference

Technological Parameter	400°C		410°C		420°C		430°C
Technological Parameter	CS(MPa)	DOL(um)	CS(MPa)	DOL(um)	CS(MPa)	DOL(um)	CS(MPa)	DOL(um)
3H	≥650	≥7.0	≥650	≥8.0	≥650	≥9.0	≥650	≥10.5
4H	≥600	≥8.0	≥600	≥9.0	≥600	≥11.0	≥600	≥12.5
5H	≥600	≥9.0	≥600	≥10.0	≥600	≥11.5	≥600	≥13.0

Note: Tempering solution Na+<0.5%. The above test results are affected by processing conditions, the data is for reference only, not as a basis for production.


Storage
Storage conditions: Temperature ≤30℃, humidity ≤65% (no condensation), shelf life is 6 months from the date of delivery.
